TStyledToolbar Demo

Overview

This demo compares TStyledToolbar with the standard VCL TToolBar, showing how to create modern-looking toolbars with styled buttons while maintaining full compatibility.

What You'll Learn

• How to create TStyledToolbar dynamically
• Adding styled tool buttons with different styles
• Comparison with standard TToolBar
• Using separators and dividers
• Configuring toolbar appearance options
• Button sizing and layout

Toolbar Comparison

The demo creates two toolbars side-by-side:

Standard TToolBar (Left)

Shows the classic VCL TToolBar for comparison.

TStyledToolbar (Right)

Modern styled toolbar with:

• Individual button styling (Family/Class/Appearance)
• Consistent appearance across Windows versions
• Full customization options

Dynamic Toolbar Creation

Creating Standard ToolBar

procedure TfmStyledToolbar.CreateToolBar;
begin
  FToolBar := TToolBar.Create(Self);
  FToolBar.Flat := True;
  FToolBar.ShowCaptions := SHOW_CAPTIONS;
  FToolBar.AutoSize := TOOLBAR_AUTOSIZE;
  FToolBar.Images := VirtualImageList;
  FToolBar.ButtonWidth := BUTTON_WIDTH;
  FToolBar.ButtonHeight := BUTTON_HEIGHT;
  FToolBar.Parent := Self;
end;

Creating TStyledToolbar

procedure TfmStyledToolbar.CreateStyledToolBar;
begin
  FStyledToolBar := TStyledToolBar.Create(Self);
  FStyledToolBar.ShowCaptions := SHOW_CAPTIONS;
  FStyledToolBar.AutoSize := TOOLBAR_AUTOSIZE;
  FStyledToolBar.Images := VirtualImageList;
  FStyledToolBar.ButtonWidth := BUTTON_WIDTH;
  FStyledToolBar.ButtonHeight := BUTTON_HEIGHT;
  FStyledToolBar.Parent := Self;
end;

Adding Toolbar Buttons

Standard Buttons

function TfmStyledToolbar.AddButtonToToolbar(
  var AToolbar: TToolBar;
  ACaption: string;
  AStyle: TToolButtonStyle;
  AImageIndex: Integer): TToolButton;
begin
  Result := TToolButton.Create(Self);
  Result.Style := AStyle;
  Result.Caption := ACaption;
  Result.ImageIndex := AImageIndex;
  Result.Parent := AToolbar;
end;

Styled Buttons

function TfmStyledToolbar.AddStyledButtonToToolbar(
  var AToolbar: TStyledToolBar;
  const ACaption: string;
  const AStyle: TToolButtonStyle;
  AImageIndex: Integer;
  const AFamily: TStyledButtonFamily;
  const AClass: TStyledButtonClass;
  const AAppearance: TStyledButtonAppearance): TStyledToolButton;
begin
  if AToolbar.NewButton(Result, AStyle) then
  begin
    Result.Caption := ACaption;
    Result.ImageIndex := AImageIndex;
    Result.SetButtonStyle(AFamily, AClass, AAppearance);
  end;
end;

Button Styles

The demo uses different Bootstrap styles for each button:

// Button 1 - Primary Outline
AddStyledButtonToToolbar(FStyledToolBar, 'Caption1', tbsButton, 0,
  BOOTSTRAP_FAMILY, btn_primary, BOOTSTRAP_OUTLINE);

// Button 2 - Secondary Outline
AddStyledButtonToToolbar(FStyledToolBar, 'Caption2', tbsButton, 5,
  BOOTSTRAP_FAMILY, btn_secondary, BOOTSTRAP_OUTLINE);

// Divider
AddStyledButtonToToolbar(FStyledToolBar, '', tbsDivider);

// Button 3 - Success Outline
AddStyledButtonToToolbar(FStyledToolBar, 'Caption3', tbsButton, 8,
  BOOTSTRAP_FAMILY, btn_success, BOOTSTRAP_OUTLINE);

// Separator
AddStyledButtonToToolbar(FStyledToolBar, '', tbsSeparator);

// Button 4 - Danger Outline
AddStyledButtonToToolbar(FStyledToolBar, 'Caption4', tbsButton, 10,
  BOOTSTRAP_FAMILY, btn_danger, BOOTSTRAP_OUTLINE);

Toolbar Appearance Options

Show Captions

Toggle button captions on/off:

StyledToolBar.ShowCaptions := ShowCaptionCheckBox.Checked;

Flat Style

Enable/disable flat appearance:

StyledToolBar.Flat := FlatCheckBox.Checked;

List Mode

Display buttons in list style:

StyledToolBar.List := ListCheckBox.Checked;

Button Sizing

Adjust button dimensions with trackbars:

StyledToolBar.ButtonWidth := tbWidth.Position;
StyledToolBar.ButtonHeight := tbHeight.Position;

Button Types

Normal Buttons (tbsButton)

Standard clickable toolbar buttons.

Separators (tbsSeparator)

Thin vertical divider between buttons.

Dividers (tbsDivider)

Thicker visual separation between button groups.

Check Buttons (tbsCheck)

Toggle buttons that stay pressed.

Dropdown Buttons (tbsDropDown)

Buttons with dropdown menus (with popup menu assigned).

Interactive Controls

The demo includes controls to modify toolbar appearance:

Control	Function
Width Trackbar	Adjust button width
Height Trackbar	Adjust button height
Show Caption	Toggle captions visibility
List	Switch to list mode
Flat	Toggle flat appearance

Changes apply to both toolbars simultaneously for easy comparison.

Creating Toolbar Programmatically

Full example of creating a styled toolbar:

var
  Toolbar: TStyledToolbar;
  Btn: TStyledToolButton;
begin
  // Create toolbar
  Toolbar := TStyledToolbar.Create(Self);
  Toolbar.Parent := Self;
  Toolbar.Images := ImageList1;
  Toolbar.ShowCaptions := True;

  // Add button
  if Toolbar.NewButton(Btn, tbsButton) then
  begin
    Btn.Caption := 'New';
    Btn.ImageIndex := 0;
    Btn.SetButtonStyle(BOOTSTRAP_FAMILY, btn_primary, BOOTSTRAP_NORMAL);
    Btn.OnClick := NewButtonClick;
  end;

  // Add separator
  Toolbar.NewButton(Btn, tbsSeparator);

  // Add more buttons...
end;

Popup Menus

Toolbar buttons support popup menus:

TlbButton.DropDownMenu := PopupMenu1;

When clicked, the dropdown menu appears.

Key Differences from TToolBar

While fully compatible, TStyledToolbar adds:

1. Per-Button Styling: Each button can have its own Family/Class/Appearance
2. Consistent Rendering: Same look across all Windows versions
3. Modern Appearance: Bootstrap, Angular, or custom styles
4. Better DPI Support: Automatic scaling
5. Enhanced Customization: More control over appearance

Design-Time vs. Runtime

The demo shows both approaches:

• Design-Time: Toolbar created in form designer (visible at startup)
• Runtime: Toolbar created dynamically when clicking "Create" button

Both approaches support the same features.

Technical Details

Source Location

Demos/source/StyledToolbarForm.pas

Supported Versions

All Delphi versions (XE6+)

Key Properties

Property	Description
ButtonWidth	Width of toolbar buttons
ButtonHeight	Height of toolbar buttons
ShowCaptions	Display button captions
Flat	Flat appearance mode
List	List display mode
AutoSize	Auto-resize to fit content
Wrapable	Allow buttons to wrap
Images	ImageList for button icons

Key Methods

Method	Description
NewButton()	Create and add new toolbar button
ClearButtons()	Remove all buttons
SetToolbarStyle()	Apply style to all buttons

See Also

• TStyledToolbar Reference - Complete technical documentation
• TStyledButton Reference - Base button component
